Alloy R41

alloy R41, UNS N07041, Rene41, W.Nr.2.4665, Hyness alloy R41, J1610, carpenter41

In the range of 650-900°C, it has high tensile and durable and creep strength and good oxidation resistance. It is suitable for manufacturing high temperature parts of aviation and aerospace engines that require high strength below 870℃ and oxidation resistance below 980℃.

Physical properties

Melting point: 1316-1371 ℃

Density: 8.27 g/cm3

Hardness: ≤363 (HBS)

Magnetic: <1.002 H/m

Executive standard

AMS 5545

AMS 5712

AMS 5713

Processing

Formability

The steel ingot should be homogenized before forging, and the forging heating temperature is 1100℃~1180℃.

Parts heat treatment process

1. Working at a lower temperature, the parts are required to have high tensile strength and fatigue performance, using 1080 ℃, air cooling +760 ℃, 16H, air cooling

2. When working at high temperature and requiring high thermal strength, the heat treatment specification is 1180℃, air cooling +900℃ 4H, air cooling.

Welding process

Alloys can be welded by fusion welding, diffusion welding, friction welding and other methods.

Application field

l Aeroengine components

l Engine compressor disc, turbine disc, bearing ring

l Receiver, supercharger, turbine wheels

l Afterburner parts and fasteners

l Fasteners and plate welding bearing parts
